Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 298
er is inserted so that the burr leftwill be taken off. The oil hole is counter-sunk with alarger drill or a regular counter-sink. The pulley is machined next. This is accomplished asdescribed in Chapter XII and the writer believes thiswill be too fresh in the mechanics mind to require a… … •3 bo -n^/S- 298 Shop Practice for Home Mechanics pad is then placed in tlie tail stock of the lathe and bythe aid of a large V-block the hole for the set screw isdrilled in the pulley with a No. 26 drill and tapped outto receive a 1-24 machine screw. The hole is counter-bored with a 14-inch drill…
Machine-shop practice · Handicraft
