A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .. (1873)

[Scott, David] engineer. [from old catalog] · New York, D. Appleton and company · leaf 94

An illustration from A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .., 1873, leaf 94
e face of the cogs, as described. And lastly. Making that part of the guide-bar which rests against the guide-plate to determine theform of the face of the cogs separate from, and movable on, the guide-bar, and properly bevelled torelieve and clear the cutter for its back movement, substantially as… … inches face. This is a hea\7 and strong-built machine, adapted to cutting spiral spur and bevel geers,without any additional fixtures. M is the spindle to which the geers are fastened when being cut, and to which is attached the dial 88 GEER-CUTTING ENGINE. plate B, on the upper surface of which…

Gearing · Mills and mill-work · Odontograph
