one-pulley for driving feed-shaft. It runs loose on a stud, and has a pinion on inner endto drive the two worms. E, worms—one right, the other left—which drive the two worm-wheels so as to feed towards the rightor left, as the operator may wish. On the worm-geer shaft there is a pinion driving a… … 134 LATHE.
