Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 168
; the uniform magnetic field has a direction downward, asshown by the vertical arrows; and a battery of cells at E cansend a current through the circuit DBAF in a counterclockwisedirection. Under such conditions the sliding conductor AB willtend to move to the left as indicated by the arrow M, and… … Fig. 6 Graphic Representation of Left-Hand Rulg for Induced Currents 155 12 DESIGN OF SMALL TRANSFORMERS whenever the number of lines threading through a circuit isdecreased, the induced pressure is clockwise around such anarrangement as represented by Fig. 7. This is just the reverse ofthe…
Electric motors · Electric transformers · Electromagnets · Induction coils
