Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 198
or winding distance. To find if there is sufficientwinding space inside the core legs to accommodate the requirednumber of secondary turns, it will be necessary to refer to col-umn F, Table II to ascertain the diameter of No. 26 double-covered wire, which is 0.0249 inch. The number of possible… … Fig. 26. Dimensions of Parts of Transformer equals 1.245 inches. As there is a distance of 9 inches betweenthe two legs of the core, there are 4.5 inches for the turns ofboth primary and secondary on each leg. The outside diameterof the completed primary should not be over 6 inches, whichallows 21…
Electric motors · Electric transformers · Electromagnets · Induction coils
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
