Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 75
somewhat lower density; teeth Sand 8 still lower; teeth 2 and 9 still lower; and teeth 1 and 10zero density at the particular instant of time under consider-ation. The same will be true for each of the other three quar-ters. The main winding will be distributed as shown, exceptthat the number of… … MULTIPLY CONDUCTORS IN EACH 5L01T0RIN6 BY Ki -21 TO PIN6 Fig. 26. Main Winding for Western Electric Type SA, Frame 137 Motor each slot will be multiplied by a factor K2. It will be notedthat the coil centers of the starting winding will lie midwaybetween the coil centers of the main winding, so…
Electric motors · Electric transformers · Electromagnets · Induction coils
