Fig. 92.—Wave Winding. 90 is shown with a lap winding. The development given inFig. 93 distinctly shows the zigzag form of the wave winding.In multipolar machines, the wave winding can be used forseries as well as for parallel connection; the lap winding,however, for parallel grouping only. §44]… … e[ I hiFig. 93-—Development of Wave Winding. For series-parallel connection, either wave winding may beused or lap and wave windings may be combined. Fig. 94represents the development of such a mixed winding, the
