Specifications for the multiplex printing telegraph system : theory and operation (1920)
Western Union Telegraph Company · [New York?] : The Company · leaf 216
Resetthe clamp screw. 4. Removal of Type Bars. Referring to Figure 5 it will be seen that by pushing theuniversal bar back out of the way the type bar may be lifted from the fulcrum rod andpulled forward so that this rod passes through the opening in the type bar. It is thena simple matter to… … FRONT STOP SCREWFOR OPERATINGLEVER RESTORING BAR Fig. 11 Page 2 Section 5-B Adjustments Multiplex System 263-C 5. Type Bar Pad. The purpose of the type bar pad is to form a rest for the typebars and its construction cuts down to a minimum the bounce of the type bars on theirreturn strokes. If a bar…
Telegraph
