Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth (1914)
New York, The Industrial press; [etc., etc.] · leaf 124
s has been a most prolific cause of noisy gearing. 108 NOISY GEARING 109 4. — The faulty alignment of the shafts on which the gearsare mounted produces a jamming action, causing an objection-able grinding noise. Even if the alignment is perfect whenthe gears are erected, the shafts are practically… … Figs. I and 2. Diagrammatical View showing Effect of Disalignment sume that the action between the teeth is perfect and that,therefore, the pressure between the teeth is at all times in exactlythe same direction relative to the pitch circles. This pressuretends to force B in the direction of the…
