Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth (1914)
New York, The Industrial press; [etc., etc.] · leaf 293
ight, seldom exceeding 0.012 to 0.015 inch. Withthe work located in this way, the pitch hne of tooth face ON alsocoincides with the surface of the pitch cone. Fig. 5 shows theamount X by which the cut taken by this method exceeds thecorrect depth at the inner ends of the teeth. CHAPTER XIV LONG AND… … STANDARD 14H INVOLUTE14 TOOTH PINION
Gearing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
