cle with a radius of tV inch. Locatethe head-end compression of 25 per cent at I. Draw G H tangent to the VALVE GEARS 27 steam-lap and lead circles cutting the valve travel circle at G, thus estab-lishing the head-end admission. From the properties of the Zeuner diagramas discussed on pages 21 and… … Fig. 27. Diagram for Engine with Thirty Per Cent Cut-Off, Laps Equal, CompressionTwenty-Five Per Cent ing in mind the demonstrations previously given, it is evident that a line drawnfrom the point of compression on the head end / perpendicular to F 0 E willcut the valve travel circle at /, the…
