Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 158
unt, the angle betweenthe link and the block will be such that there will be an excessiveslip of the block and undue stresses in the mechanism will be induced.The angularity of the eccentric rods produces irregularities in themovement of the valve, which can be largely compensated for b;ylocating… … Fig. 54. Crossed Rod Arrangement of Eccentric Rods in Stephenson Gear tion be given to the amount of lead at full gear as well as to theincrease of lead produced by hooking up the engine. With openrods it will be seen that when in full gear the link block is at Gi,and that if, without turning the…
Indicators for steam-engines · Steam-engines
