Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 340
in Fig. 163. Perpendicular to it, at any givenpoint, erect a line, called the zero line, whose assumed length willrepresent the volume of the low-pressure cylinder plus the clear-ance. Lay off this clearance. Divide the remainder into anynumber of parts and divide the atmospheric line of the… … 120 ■100 - 80 - 604020 L. P. CYL
Steam-engines · Heat-engines
