Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 130
ctrix of the angle 203, and it is not difficult, practi-cally, to obtain the center P so that a circle can be drawn tangentto 02, 03, and the arc SS. The exhaust-opening at C gives crankposition 09, and as this precedes OP the exhaust lap Pe on thehead end is negative. For the crank end, the throw… … Fig. 77. lap. Find the crank position corresponding to exhaust-openingat C and draw the crank position 09 at exhaust-opening. Asthis position follows position OP the exhaust lap on crank end ispositive. The leads and port-openings differ considerable fromthose on the head end. Dimensions of…
Steam-engines · Heat-engines
