Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 267
e heating and cooling sides we see that,four cases may occur: Fig. 130. The hot fluid maintains a constant temperature Kand there is a continuous rise in temperature in the cold fluid;Fig. 131. The cold fluid has a constant temperature butthe hot fluid varies in temperature; Fig. 132. Both fluids… … —J SL, Fig. 132. T --):■ Fig. 133. CONDENSERS AND AIR-PUMPS. 247 This would occur in concentric tubes, one carrying the coldand the other the hot fluid; Fig. 133. Both fluids change in temperature but both flow-in opposite directions parallel to the heating surface.The following discussion is…
Steam-engines · Heat-engines
