Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 330
Xl2=9 cu. ft.Draw GF; it will be an hyperbola. … D Fig. 159. We assume that the pressures in the L.P. cyl. at the instantbefore its cut-off, at its cut-off, and the instant after its cut-off areidentical. The instant before cut-off in the L.P. cyl. the exhaustfrom the H.P. cyl. was in communication with the receiver, and thelatter was in…
Steam-engines · Heat-engines
