grammatic sketch for a Buckeye valve-gearand its Bilgram diagram for a 20X36 engine, making 125 revolu-tions per minute, lead of the main valve, 1/16 in.; maximum cut-off,.8 stroke; minimum cut-off at the beginning of the stroke; exhaustopens and closes at .9 stroke; connecting-rod, 9 feet long;… … Fig. 194.—Meyer Valve. that rides on the main valve. The main valve governs the latestpoint of steam cut-off and the points of exhaust opening andclosure. The earlier points of cut-off can be varied by adjusting,by hand, the distance b?tween the cut-off blocks. Means are pro-vided for rotating the…
