Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 199
Fig. 203.—Direct-Acting Boiler-Feed Pump Equipped With Fulton Governor. In plants of over 500 h.p., they may be either reciprocatingor centrifugal pumps (Fig. 204). Multistage Cen- ,-Fzed Pipe To BoilerstrifugaT Boiler \ Steam Turbine-^ PressureGovernor--^ … Fia. 204. ^Suction Pipe From Feed- Water Heater -Fxhaust Pipe -Centrifugal Boiler-Feed Pump Driven By Steam Turbine Through DirectShaft Connection. 205. The Possible Losses Due To Inefficient Boiler-FeedPumps Are, In The Average Plant, A Very Small Proportion OfThe Total Losses.—The total coal…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
