Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 518
Fig. 259. Fig. 260. The indicator-card and entropy diagram are represented inFigs. 193 and 194, but not to scale. The diagrams are lettered to … Fig. 261.—Valves of Diesel Engine. 497 GAS-EXGIXES AND GAS-PRODUCERS. 499 indicate the same events. AB is the suction; BC is the compres-sion; CD is the preliminary and DB the after or isothermal heatlines due to the gradual combustion of the injected oil; EF is theadiabatic expansion line; and FB…
Steam-engines · Heat-engines
