Goldingham, Arthur Hugh. [from old catalog] · New York, Spon & Chamberlain; [etc., etc.] · leaf 48
ction stroke the automatic air-inletvalve is opened by the partial vacuum in the cylinder,and the oil which has entered through the small holesat the inlet valve is drawn through the heated vaporizerinto the cylinder. At the compression stroke the mix-ture of the vapor is completed, and being… … AM.BANK NOTE CO.! Fig. 6. (To face />. 12.) INTRODUCTORY. 13 vaporizer as well as the tube. The governing iseffected by allowing the exhaust-valve to remain openwhen the normal speed is exceeded; consequently nocharge is in that case drawn into the cylinder. Sprayers.—The oil-spraying device of…
Internal combustion engines
