Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 62
ht hand end of the connecting rod shown in Fig. 36 PARTS OF THE STEAM ENGINE 47 is of the marine type; the left-hand end is of the box type,described before. Marine end connecting rods are used on allmarine engines and on some vertical stationary ones. Theexample shown here is from a stationary… … Fig. 36. of bolts placed parallel to the connecting rod and passing throughshoulders on the rod and on the removable end, as shown. Thisform of adjusting device permits a short end for the rod, whichaccounts for its common use on marine engines, where the crankpin passes close to the floor. Crank…
Steam-engines
