Steam engines, prepared in the Extension division of the University of Wisconsin (1919)

Shealy, Edward Marvin · New York, McGraw-Hill · leaf 65

An illustration from Steam engines, prepared in the Extension division of the University of Wisconsin, 1919, leaf 65 — Fig. 42. Large horizontal engines usually have main bearings of the typeshown in Fig. 43. In this type the bearing is divided into fourparts, the side pieces being adjustable. One of these side pieces … Fig. 43. is adjusted by shims and the other by set screws passing throughthe frame. The top part of the bearing is made as a part of the PARTS OF THE STEAM ENGINE 51 cap, which is held in place by bolts passing down into the frameand which serves to hold the parts of the bearing together.…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
