ce condenser,or mingle with a spray of water, as in a jet condenser. These twotypes will now be discussed. Types of Condensers. Condensers may be divided into twogeneral classes as follows: (1) Surface condensers in which the cooling water is separatedfrom the steam, usually by metallic surfaces in… … Fig. 77. Diagram Showing Relation of Surface Condenser to the Pumps Necessary for Proper Operation condensers, ejector condensers, etc., in which the cooling watermingles with the steam to be condensed. Surface Type. The condenser shown in section in Fig. 76 is oneform of the surface type, in wmich…
