Steam engines, a thorough and practical presentation of modern steam engine practice (1920)

Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 145

An illustration from Steam engines, a thorough and practical presentation of modern steam engine practice, 1920, leaf 145 — Fig. 78. LongUodinal Section of Independent Jet Condenser and Pump … WATER DISTRIBUTINGTRAY AIR PUMP SUCTION

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
