e-retaining ring. ACTION OF THE LAMPS. 16. The special features of the lamps just described arethe closed globe A, the white porcelain reflectors g and h(placed in the upper part of the globe above the flames, withan annular opening between them), and the peculiar manner inwhich the air supply to… … Fig. 14. 16 CAR LIGHTING. § 12 the result being increased whiteness and steadiness of light.It will also be noticed in all the lamps here shown, that thedesign is such as to reflect some of the light upwards throughthe mica chimney i and dome B, and so illuminate the roof ofthe car. As seen in Fig.…
