Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 183
Fig. 96. Standard Typeof Simple Oil Cup 166 STEAM ENGINES … Fig. 97. Jorrn of Wiper Crank Pin Oiler A form of wiper crank pin oiler is shown in Fig. 97. The oilcup is attached to a bracket. The oil drops from the cup into the sheet of wicking or wire clothand is removed at each rev-olution of the crank pin bymeans of the cup which isattached to the end of…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
