Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 186
pump A, usually driven from thegovernor shaft, pumps the oil through the cooler C, thence throughpipes D to the various bearings. The relief valve L by-passes anyexcess oil back into the storage reservoir B. In some systems theoil is pumped into an overhead reservoir from which it is allowedto flow… … bearings at the top and flows out at each end, where it dropsdown into chambers in the turbine casing and is collected by the 170 STEAM ENGINES pipe J and returned to the reservoir B. A screen K is providedin the reservoir which removes any large particles of foreign matter.In such a system there…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
