IS … STEAM ENGINES 49 gas at various points in their respective paths. The figure is self-explanatory, except that the feed-water heater, condenser, andvacuum pump shown in the upper right-hand corner are put theremerely for convenience of illustration. In the actual locomobilethey are situated…
