Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 149
er stroke, namely, the low-pressure cylinder volumeat pressure fe, though, with throttling, the useful work area is reducedby the area p^^asp.^ The theoretical gain would not, however, be fullyrealized in practice, owing to greater loss by cylinder condensationwith an early cut-off. A similar… … Fig. 148. Thuottling Governing in H.P. Cylinder.Condensing.
Steam-engines
