Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)
Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 259
/4 7/£. Fig. 96.—H.P. Diagram. /47/A Condenser Pressure*Fig. 95.—L.P. Diagram. … zero Pk Fig. 97.—Combined Diagrams from a Compound Engine. 46 STEAM ENGINE TESTING 241 Points 5, 6, 7, etc., on the reconstructed diagram may now belocated on these verticals by scaling the pressures of the corre-sponding points of Fig. 95 from the atmospheric line. In thisway the full low-pressure…
Mechanical engineering
