Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 307
2 go STEAM-ENGINE THEORY AND PRACTICE. pressure on the foundations resulting from combinations of engines on SINGLE CRANK … l80--^--270 FiG. 345. one crank shaft may bewell seen. Single-crank VerticalEngines. — Fig. 345shows a curve, AA,which is drawn by firsttaking a horizontal line,XX, to represent theunfolded crank-pin path,and dividing it in ascale of degrees. Thenfor any number of posi-tions of the crank, avertical…
Steam-engines
