Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 59
Fig. 33. position after adjustment. The method of securing the wristpin in this crosshead is shown by the taper ends of the pin com-bined with a nut on the end. The method of carrying oil tothe rubbing surface of the pin is clearly shown. … Fig. 33a. The slipper type of crosshead, Fig. 33a, resembles the wingtype, but differs from it in having the wrist pin and main bodyof the crosshead placed above the wings. In this case the wingsare comparatively thin but the rubbing surface, which is all of thebottom of the crosshead, is broad.…
Steam-engines
