The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 19
^S\\\nWC3ZE^^^ … Fig. 1. — The Steam Plant. A. Boiler and Feed Pump. II The Boiler (Water-tube type). 1. Grate and fire space. 5. Chimney. 2. Ash pit. 6. Boiler shell or drum. 3. Hot-gas spaces. 7. Tubes. 4. Flue and damper. 8. Steam pipe. The Engine (Corliss type). 9. Throttle valve. 15. Crank. 10. Cylinder. 16.…Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
