The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 341
e not of the same size; so that if theseparate curves are to be combined, theymust either be worked out for total forceon crank, or else one piston must betaken as the chief and the pressures onthe others be referred to that one, orbe expressed as equivalent pressures perunit of area of that… … Fig. 180. — Centrifugal Force onWheel-rim. § 33 (d)] FLY-WHEEL ACTION. 325 sion of the arms being left out of account. The force tending tocause rupture at any section as AB, and resisted by tensile stress in thering, is found by getting the value of the resultants Fi, Fh each ofwhich is the sum of…
Steam-engines · Steam-turbines
