lution of the shaft, the two rodswill be part of the time clear of eachother, as here, part of the timecrossed, as in Fig. 242. The dis-tinction is made by turning the shaftso that the two eccentric centers Eiand E2 are toward the link, orbetween the link and a vertical center line through 0; and… … The Indirect Link Motion. 386 VALVE GEARS AND GOVERNORS. [Chap. VIII. senting the action of the link motion is not quite exact, because somesmall secondary movements of the link are not taken into account.Further, the proof of the statements as to proportionality along theeccentric locus and as to…
