The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 404
Fig. 246. — Valve Diagrams for theLink Motion. Fig. 247. — Diagrams from aLocomotive. locus is first laid out at EiE0E2 (for the crank at zero), and the locusof D is made symmetrical to it, with reference to the line GH. Valvecircles are drawn, for full gear forward, on ODi; for full gear…
Steam-engines · Steam-turbines
