Steam engines, prepared in the Extension division of the University of Wisconsin (1919)
Shealy, Edward Marvin · New York, McGraw-Hill · leaf 170
m 4 to 5 caused by theadmission side of the valve opening too late, thus preventing thepressure in the cylinder from rising quickly and also causing THE VALVE DIAGRAM 155 wire-drawing. Small lead is not a good indication of a slippedeccentric because the valve may have been set originally withtoo… … Fig. 93. on the shaft, the angle of advance will become larger, and all ofthe events will occur earlier. An indicator diagram showing theresults of too great angle of advance is illustrated in Fig. 93.Too early release is shown at 3, 4, by the sharp toe of the diagram.Early admission, the result of…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
