The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 446
Fig. 294. — Counter-poise on InclinedArm. … Fig. 295. — Force Action in the Shaft Governor. curve I in Fig. 293 will be brought a little nearer to the inclinationof curve II. (/) Force Action in the Shaft Governor. — In Fig. 295, the axisof rotation is projected in the point O, and OA is a radius in the planeof the wheel, out to the pivot…
Steam-engines · Steam-turbines
