Fig. 220. —The Valve MechanismReduced. Fig. 221. — The Reuleaux Diagram. and the deductions in § 31 apply equally to the valve gear. The pres-ent problem is simphfied by the fact that the eccentric rod is usually solong, relative to the radius of the eccentric, that the valve receivespractically…
