abscissa and tem-perature is ordinate. While the gas changes state from A to B, theentropy acquired is 0.5469 X 0.30103 = 0.1646 = OD; and from A toC it is 0.3891 X 0.30103 = 0.1171 = OE. Of course, calculation must 9(6)] THE TEMPERATURE-ENTROPY ANALYSIS. 57 be made for a number of intermediate… … - Mechanical Diagram forHeating at Constant Pressure andat Constant Volume. Fig. 35. — Thermal Curves forOperations in Fig. 34. 100
