Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 103
Fig. 95.—Sectional View Of Double-Acting Triplex Pump. 82 STEAM POWER PLANT AUXILIARIES [Div. 3 87. Crank-Action Power Pumps may be divided into threemain classes: (1) Simplex power pumps (Fig. 87) in which thepumping operation is performed by a single piston or plunger, Spur Czar On Crank… … Fig. 96.—Pump Driven By Motor Through Spur Gearing. rCrunk Shaft Pulley ■-Pump
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
