Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 166
-■■Vacuum Pipe (Connected To A Vacuum System Or To An Air Pump) A/r Chamber-.^^Discharge Pipe-^^.-Driving Motor\ Centrifugai Pump … Fig. 165.—Centrifugal Pump With By-Pass. Fig. 166.—Centrifugal-Pump SuctionLine Equipped With Air-Chamber. condenser or of a heating system, or to any system of pipingin which a vacuum is maintained, the air can be removed asfast as it separates from the suction water. Note.—The Vacuum Pipe leading…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
