d a spring S takes theplace of the weight as described above. The piston, however, is acted onby the feed line pressure only and so communicates this full pressure to thespring. The tension on the spring is adjusted by means of two thumb-screws T. 200 STEAM POWER PLANT AUXILIARIES [Div. 6 233. The… … Suction Pice From Feed- Water HeaterFig. 213.—Direct-Acting Boiler-Feed Pump Equipped With Fisher Governor. Steam Mam--^ From Main Steam Line To Under SideOf Diaphragm- /Main Feed Line To Boilers \ From, Main Feed Line To Upper Side Of Diaphragm SteamSupply ToPump-,
