Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 303
f power developedconstant, instead of keepingthe amount of steam used con-stant as on Fig. 284. 323. The Steam SavingDue To A Condenser OnThe Basis Of DecreasedBack Pressure may be de-termined very closely bythe use of a suitable graph(Fig. 286). First the non-condensing steam consump-tion is… … 20 40 60 80 100 120 140 160 180 200Initial S+eam Pressure AbsoluteLb. Per Sq. In Fig. 286.—Diagram Showing The SteamConsumption Of A Perfect Steam Engine WhenReceiving Steam At Different Pressures AndExhausting Against Different Back Pressures.(Note bad effect of high back pressure. Thesteam…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
