Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 357
© b- »o © © o t^ 00 © © 336 STEAM POWER: PLANT AUXILIARIES [Div. 10 394. The Weight Of Water Vapor Which Is Contained InA Cubic Foot Of Atmospheric Air Is Determined By The Tem-perature And The Relative Humidity Of The Air.—The graphFig,. 315 indicates the relation between temperature and weight… … 20 40 60 80 100 120Air Temperature in Degrees Fahrenheit Fig. 315.—Graph Showing Re-lation Between Temperature AndWeight Of Water Vapor In 1 Cu.Ft. Of Air Of 100 Per Cent. Rela-tive Humidity. Example.—The temperature of a cer-tain volume of air is 100 deg. fahr. Itsrelative humidity is 55 per cent.…Steam power plants · Pumping machinery
