Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 99
Discharge Valves- Fig. 89.—A Belt-Driven Double-Acting Fig. 90.—Belt Driven Single-Acting PlungerPump For Boiler Feeding. Pump For Boiler Feeding. .-Flywheel … SuctionInlet-■■■ Fig. 91.—Single-Acting Crank-And-Flywheel Pump For Hydraulic Elevator Service. action entirely obviates the short-stroking of the pistons (Sec. 75) whichis liable to occur with direct-acting pumps. Also, since the limits of Sec. 85] CRANK-ACTION PUMPS 79 the piston stroke are…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
