Fig. 121. Data for a Plate Girder Design are of much assistance in arriving at the approximate section of therequired girder, but usually the final design must be computed indetail, as in the foregoing example. … MOMENT OF INERTIA Fig. 122. Diagram for Determining MomentsAfter Deducting Rivet Holes. 2 Holes, % (.% Rivets) for K The large number of plate girder sections that it is possible tomake up from the available sizes of web plates, flange angles, andflange plates makes it impracticable to have…
