Fig. 79.—Enlarged View of Coffer-dam, showing Diaphragm Plates, Trunk-wayto Tunnel, and Ventilating Pipe. 00 o Li. iL S … TYPES OF VESSELS—SECTION II. I 57 tween decks are connected to the beams at their upper extremity, andto the deck at the lower extremity, by means of bracket knees. Theexpansion trunk (see fig. 78) is fitted all fore and aft in the tween decks,and its sides are supported by webs of plating at…
