Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture (1875)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 50

An illustration from Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture, 1875, leaf 50
is problem includes the following simpler cases, added asexamples. Examples. — 1°. Let both ends be plane; one, vertical on PQ ; the other ver-tical on JR. Ex. 2°. Let the cylindrical end be replaced by a plane one, having JR. for itshorizontal trace, and a batter of ^. Ex. 3°. Construct a rampant… … Fig. 3. 30 STEREOTOMY. is usually cylindrical. They are distinguished from each otheras follows : — In the groined arch, Fig. 3, that part of each cylinder is realwhich is exterior to the other. Thus EF, LM, eF, and KH arereal portions of elements. In the cloistered arch, that part of each cylinder…

Stereotomy

Internet Archive · UNC Libraries · Public Domain Mark 1.0. Free to use for anything.
