The American house-carpenter; a treatise on the art of building, and the strength of materials (1873)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 381
will fall, in the line, c e, until it lies directly behind the point, e,and the line, b c, will lie directly behind b e. … Fig. 823. 484.— To find the bevils for splayed work. The principleemployed in the last figure is one that will serve to find the bevilsfor splayed work—such as hoppers, bread-trays, &c.—and a wayof applying it to that purpose had better, perhaps, be introducedin this connection. In Fig. 323, a…
